STAHL
Product Ref Dimensions Teeth Description
200.742.01.00 46,5x30x0,8   Scoring / Creasing Blade
200.742.02.00 46x30x0,8   Scoring / Creasing Blade
200.742.03.00 45,5x30x0,8   Scoring / Creasing Blade
200.742.04.00 45x30x0,8   Scoring / Creasing Blade
200.742.05.00 61x40x0,8   Scoring / Creasing Blade
200.742.06.00 60x40x0,8   Scoring / Creasing Blade
200.742.07.00 78x55x0,8   Scoring / Creasing Blade
200.742.08.00 77x55x0,8   Scoring / Creasing Blade
200.742.09.00 59,5x40x0,8   Scoring / Creasing Blade
200.742.10.00 38x26x0,8   Scoring / Creasing Blade
200.742.11.00 37,5x26x0,8   Scoring / Creasing Blade
200.742.12.00 59x40x0,8   Scoring / Creasing Blade
200.742.13.00 37x26x0,8   Scoring / Creasing Blade
200.742.14.00 76x55x0,8   Scoring / Creasing Blade
200.742.15.00 76,5x55x0,8   Scoring / Creasing Blade
200.747.01.00 48x30x0,5   Slitter / Cutter Blade
200.747.02.00 55x30x0,5   Slitter / Cutter Blade
200.747.03.00 61,5x40x0,5   Slitter / Cutter Blade
200.747.04.00 60x40x0,5   Slitter / Cutter Blade
200.747.05.00 63,5x40x0,5   Slitter / Cutter Blade
200.747.06.00 62,5x40x0,5   Slitter / Cutter Blade
200.747.07.00 78,5x55x0,5   Slitter / Cutter Blade
200.747.08.00 77x55x0,5   Slitter / Cutter Blade
200.747.10.00 46x30x0,5   Slitter / Cutter Blade
200.747.11.00 39x26x0,5   Slitter / Cutter Blade
200.748.01.00 79x55x0,5 18 Perforating Blade
200.748.02.00 79x55x0,5 30 Perforating Blade
200.748.03.00 79x55x0,5 40 Perforating Blade
200.748.04.00 79x55x0,5 9 Perforating Blade
200.749.01.00 62x40x0,5 12 Perforating Blade
200.749.02.00 62x40x0,5 18 Perforating Blade
200.749.03.00 62x40x0,5 40 Perforating Blade
200.750.01.00 48x30x0,5 15 Perforating Blade
200.750.02.00 48x30x0,5 10 Perforating Blade
200.750.03.00 46x30x0,5 15 Perforating Blade
200.750.04.00 46x30x0,5 10 Perforating Blade
200.750.05.00 39x26x0,5 15 Perforating Blade
200.750.06.00 39x26x0,5 10 Perforating Blade
200.753.01.00 60,5x40x2   Scoring / Creasing Blade
200.754.01.00 59,5x40x0,5 80 Perforating Blade
200.754.02.00 59,7x40x0,5 80 Perforating Blade
200.754.03.00 59x40x0,5 80 Perforating Blade
200.754.04.00 60x40x0,5 80 Perforating Blade
200.754.05.00 61,5x40x0,5 60 Perforating Blade
200.754.06.00 59x40x0,5 60 Perforating Blade
200.754.07.00 61,5x40x0,5 90 Perforating Blade
200.754.08.00 60x40x0,5 60 Perforating Blade
200.755.01.00 76,5x55x0,5 70 Perforating Blade
200.756.01.00 61,5x40x0,5 30 Perforating Blade
200.756.02.00 61,5x40x0,5 32 Perforating Blade
200.756.03.00 61,5x40x0,5 36 Perforating Blade
200.756.04.00 61,5x40x0,5 45 Perforating Blade
200.756.05.00 61,5x40x0,5 48 Perforating Blade
200.756.06.00 61,5x40x0,5 60 Perforating Blade
200.756.07.00 61,5x40x0,5 6 Perforating Blade
200.756.08.00 61,5x40x0,5 8 Perforating Blade
200.756.09.00 61,5x40x0,5 15 Perforating Blade
200.756.10.00 61x40x0,5 60 Perforating Blade
200.756.11.00 61x40x0,5 60 Perforating Blade
200.756.12.00 59,7x40x0,5 36 Perforating Blade
200.758.01.00 46x30x0,5 30 Perforating Blade
200.758.02.00 48x30x0,5 30 Perforating Blade
200.758.03.00 46x30x0,5 40 Perforating Blade
200.758.04.00 48x30x0,5 40 Perforating Blade
200.758.05.00 45,4x30x0,5 60 Perforating Blade
200.758.06.00 48x30x0,5 60 Perforating Blade
200.759.01.00 48x30x0,5 5 Perforating Blade
200.759.02.00 48x30x0,5 3 Perforating Blade
200.759.03.00 48x30x0,5 18 Perforating Blade
200.759.04.00 48x30x0,5 6 Perforating Blade
200.759.05.00 48x30x0,5 12 Perforating Blade
200.759.06.00 48x30x0,5 72 Perforating Blade
200.761.01.00 48x30x0,5 9 Perforating Blade
200.764.01.00 48x30x0,5 15 Perforating Blade
200.765.01.00 61,5x40x0,5 18 Perforating Blade
200.766.01.00 48x30x0,5 10 Perforating Blade
200.766.02.00 48x30x0,5 5 Perforating Blade
200.766.03.00 48x30x0,5 15 Perforating Blade
200.769.01.00 62x40x0,5 15 Perforating Blade
200.769.02.00 61,5x40x0,5 5 Perforating Blade
200.771.01.00 44,5x30x0,5 10 Perforating Blade
200.771.02.00 44,5x30x0,5 8 Perforating Blade
200.771.03.00 44,5x30x0,5 15 Perforating Blade
200.771.04.00 44,5x30x0,5 10 Perforating Blade
202.060.01.00 48x30x0,5 6 Perforating Blade

STAHL
Product Ref Dimensions Teeth Description
203.413.01.00 48x27x0,5 12 Perforating Blade
205.485.01.00 48x30x0,5 12 Perforating Blade
205.605.01.00 48x27x0,5 24 Perforating Blade
205.970.01.00 61x40x2   Slitter / Cutter Blade
205.970.02.00 64x40x2   Slitter / Cutter Blade
205.970.03.00 69x40x2   Slitter / Cutter Blade
205.970.04.00 51x30x2   Slitter / Cutter Blade
205.970.05.00 48x30x2   Slitter / Cutter Blade
205.970.06.00 38x26x1,2   Slitter / Cutter Blade
205.972.01.00 78,5x55x2   Slitter / Cutter Blade
205.972.02.00 77,5x55x2   Slitter / Cutter Blade
205.972.03.00 64x40x2   Slitter / Cutter Blade
205.977.01.00 78,5x55x0,5 9 Perforating Blade
205.978.02.00 62x40x0,5 18 Perforating Blade
205.980.01.00 48x30x0,5 10 Perforating Blade
205.980.02.00 48x30x0,5 5 Perforating Blade
205.981.01.00 79x55x0,5 30 Perforating Blade
205.981.02.00 79x55x0,5 18 Perforating Blade
205.985.03.00 44,6x30x0,5 60 Perforating Blade
205.985.04.00 45x30x0,5 60 Perforating Blade
205.990.01.00 48x30x0,5 24 Perforating Blade
205.990.02.00 48x30x0,5 24 Perforating Blade
205.990.03.00 48x30x0,5 24 Perforating Blade
205.990.05.00 48x30x0,5 8 Perforating Blade
205.990.07.00 48x30x0,5 10 Perforating Blade
205.990.08.00 48x30x0,5 12 Perforating Blade
205.990.10.00 48x30x0,5 24 Perforating Blade
205.990.11.00 46x30x0,5 24 Perforating Blade
210.621.01.00 61,5x40x0,5 28 Perforating Blade
213.027.01.00 64x40x0,9 12 Perforating Blade
213.028.01.00 64x40x1,2 12 Perforating Blade
213.031.01.00 81x55x0,9 16 Perforating Blade
213.032.01.00 81x55x1,2 16 Perforating Blade
213.037.01.00 50,5x30x0,9 10 Perforating Blade
213.038.01.00 50,5x30x1,2 10 Perforating Blade
213.221.01.00 48x30x0,5 6 Perforating Blade
217.636.01.00 37,5x26x0,5 40 Perforating Blade
217.636.02.00 37,5x26x0,5 60 Perforating Blade
224.773.01.00 61,5x40x2 9 Perforating Blade
224.773.02.00 61,5x40x2 12 Perforating Blade
224.773.03.00 61,5x40x2 18 Perforating Blade
224.930.01.00 39x26x2 20 Perforating Blade
224.921.01.00 78x55x2 30 Perforating Blade
226.341.01.00 39x26x1   Slitter / Cutter Blade
226.341.02.00 47,5x30x1   Slitter / Cutter Blade
226.341.03.00 61,5x40x1   Slitter / Cutter Blade
226.341.04.00 78,5x55x1   Slitter / Cutter Blade
226.348.01.00 47,5x30x1 10 Perforating Blade
226.348.02.00 47,5x30x1 10 Perforating Blade
226.348.03.00 47,5x30x1 10 Perforating Blade
226.348.04.00 47,5x30x1 15 Perforating Blade
226.349.01.00 78,5x55x1 70 Perforating Blade
226.349.02.00 78,5x55x1 30 Perforating Blade
226.349.03.00 78,5x55x1 18 Perforating Blade
226.349.04.00 78,5x55x1 30 Perforating Blade
226.350.01.00 61,5x40x0,5 60 Perforating Blade
226.350.02.00 61,5x40x1 18 Perforating Blade
226.350.03.00 61,5x40x1 12 Perforating Blade
226.350.04.00 61,5x40x1 18 Perforating Blade
226.401.01.00 61,5x40x2 12 Perforating Blade
226.401.02.00 61,5x40x2 18 Perforating Blade
226.401.03.00 61,5x40x2 12 Perforating Blade
226.401.04.00 61,5x40x1 18 Perforating Blade
226.402.01.00 47,5x30x2 10 Perforating Blade
226.402.02.00 47,5x30x2 15 Perforating Blade
226.402.03.00 47,5x30x2 10 Perforating Blade
226.402.04.00 47,5x30x2 15 Perforating Blade
226.403.01.00 78,5x55x2 18 Perforating Blade
226.403.02.00 78,5x55x2 30 Perforating Blade
226.403.03.00 78,5x55x2 18 Perforating Blade
226.403.04.00 78,5x55x2 30 Perforating Blade
226.404.01.00 78,5x55x2 18 Perforating Blade
226.404.02.00 78,5x55x2 30 Perforating Blade
226.405.01.00 47,5x30x2 10 Perforating Blade
226.405.02.00 47,5x30x2 15 Perforating Blade
271.810.01.00 78,5x55x0,5 24 Perforating Blade
273.918.01.00 61,1x40x2 24 Perforating Blade
